eSORBA® FriKon (FK) - FK J Series
| Product code |
FK JxxxSD |
xxx : thickness |
| Thickness(mm) |
0.5~3.0 |
Thickness Gauge |
Density of foam (g/㎤)
|
0.50 |
ASTM D3574-05 |
| Standard
Color |
black |
|
| Tensile strength (kgf/㎠) |
27.9 |
ASTM D3574-05 |
| Elongation (%) |
129 |
ASTM D3574-05 |
| Tear strength (kgf/㎝) |
1.76 |
ASTM D3574-05 |
| CFD*1)(kgf/㎠) |
25% |
4.9 |
ASTM D3574-05 |
| 50% |
27.62 |
|
| Hardness (ASKER C) |
75 |
ASTM D2240-91 |
| Compression Set (%) |
23℃ |
1.8 |
ASTM D3574-05 |
| 70℃ |
11.2 |
ASTM D1667-76 |
| Dimensional Stability(%)*2) |
MD |
0.28 |
22 hrs at 80℃ |
| TD |
0.27 |
| Outgas*3) (%) |
0.1 |
ASTM E 595-06 |
| Water Absorption*4) (%) |
3.4 |
SAE AMS 3568A at 35℃, 85% RH |
| Embrittlement(℃) |
-30 |
SUM-10*5) |
| Recommended Upper Temperature (℃) |
70 |
SAE J-2236 |
| Resistivity |
Surface (Ω/□) |
1X1013 |
ASTM D257-92 |
| Volume (Ω-cm) |
1X1011 |
| UL*6) |
HBF |
UL94 |
*1) Compression Force Deflection (CFD)
*2) 22hrs at 80℃
*3) 24hrs at 125℃ and below 7X10-3 Pa
*4) Weight difference before and after at 23℃, 95% relative humidity for 28 hrs
*5) SK utis method
*6) The UL certifications are available on www.UL.com site
| 0.5 |
500X100 |
FK J050SD |
M |
| 0.7 |
500X50 |
FK J070SD |
M |
| 1.0 |
FK J100SD |
S |
| 1.2 |
FK J120SD |
M |
| 1.5 |
FK J150SD |
S |
| 2.0 |
FK J200SD |
S |
| 2.5 |
FK J250SD |
M |
| 3.0 |
FK J300SD |
S |
| Packing | 1 roll each , wrapped by PE bag in a carton box |
| Export Packing | Max 240 boxes in a 20ft dry container |
Please contact if other thickness is needed.
