eSORBA® SE/SU - SU Series
| Product Code | SU CxxxSD | xxx : thickness |
| Thickness (mm) | 0.5~3.0 | Thickness Gauge |
| Density (g/㎤) | 0.20 | ASTM D3574-05 |
| Standard Color | Black |
| Tensile strength (kgf/㎠) | - | ASTM D3574-05 |
| Elongation (%) | - | ASTM D3574-05 |
| Tear strength (kgf/㎝) | - | ASTM D3574-05 |
| CFD*1)(kgf/㎠) | 25% |
0.13 | ASTMD D3574-05 |
| 50% | 0.35 | |
Compression
Set(%) |
23℃ | 0.5 | ASTM D3574-05 |
| 70℃ | 1.6 | ASTM D1667-76 |
Dimensional
Stability(%)*2) | MD | 0.15 |
22 hrs at 80℃ |
| TD | <0.01 |
| Outgas*3) (%) | 2.30 | ASTM E 595-06 |
| Water Absorption*4) (%) | 1.8 | SAE AMS 3568A
at 35℃, 85% RH |
| Embrittlement (℃) | -60 | SUM-10*5) |
Recommended Upper
Temperature (℃) | 70 | SAE J-2236 |
| Resistivity | Surface
(Ω/□) | 1X1010 | ASTM D257-92 |
Volume
(Ω-cm) | 1X1011 |
| UL*6) | HBF | UL94 |
*1) Compression Force Deflection (CFD)
*2) 22hrs at 80℃
*3) 24hrs at 125℃ and below 7X10-3 Pa
*4) Weight difference before and after at 23℃, 95% relative humidity for 28 hrs
*5) SK utis method
*6) The UL certifications are available on www.UL.com site
* SU series is PET-supported grade. Therefore, mechanical properties
such as tensile strength and elongation are same with those of PET.
S = Standard; M = Made to Order
| 0.5 | SE x050SD | 500X100 | X |
| 0.7 | SE x070SD | M |
| 1.0 | SE x100SD | 500X50 | S |
| 1.2 | SE x120SD | M |
| 1.5 | SE x150SD | S |
| 2.0 | SE x200SD | S |
| 2.5 | SE x250SD | M |
| 3.0 | SE x300SD | S |
| Packing | 1 roll each , wrapped by PE bag in a carton box |
| Export Packing | Max 240 boxes in a 20ft dry container |
Please contact if other thickness is needed.
